Condition Monitoring Unit CMU 1000 Page 18
Revised 17.12.2009 HYDAC ELECTRONIC GMBH Mat.-No.: 669749
3.4.5 GSM Module CSI-F-10
1
HSI
Master
2
RS232
TxD
3
RS232
RxD
4
IOLink
L+
5
IOLink
C/Q
6
IOLink
GND
7
VDC
IN
8
VDC
IN
9
VDC
GND
10
VDC
GND
11
VDC
GND
12
VDC
GND
- X 5
CSI-F-10
HSI +U
B
GND
5 4 1 2 3
18..35 V DC / 3,5 A
