AS-i Safety Monitor for 2 AS-i circuits
Diagnostics for AS-i Monitor and networking using AS-i Master
Subject to reasonable modifications due to technical advances Id.-No.: 103336 Issue date - 24.10.2008 EUCHNER GmbH + Co. KG 89
Kohlhammerstraße 16 • D-70771 Leinfelden-Echterdingen Tel. +49/711/75 97-0 • Fax. +49/711/753316
11.4.3.5 Vendor Specific Object 10 - Device Colors OSSD 1 with component
index association
Read only.
This object contains the colors for all devices as well as additional information for
all release circuits at the time of the last shut-off of Release Circuit 1, in the order
of the component assignment index. Also sent is which devices belong to Re-
lease Circuit 1.
Coding for the states and colors
Byte Meaning
1 Bit 0 0=Configuration mode, 1=protecting mode
Bit 3 ... 1 reserved, 0
Bit 4 status 1.Y1, EDM1 (0=open)
Bit 5 status 1.Y2, Start1 (0=open)
Bit 6 status 2.Y1, EDM2 (0=open)
Bit 7 status 2.Y2, Start2 (0=open)
2 Relay status, Output 1+2
Bit 3..0 State Output 1, diag_pc.ossd[0].relay-state
Bit 7..4 State Output 2, diag_pc.ossd[1].relay-state
3..8 ...
9 Relay status, Output 15+16
Bit 3..0 State Output 15, diag_pc.ossd[14].relay-state
Bit 7..4 State Output 16, diag_pc.ossd[15].relay-state
10 Bit field for devices which are present. Device 7 ... 0
11 ... 40 ...
41 Bit field for devices which are present. Device 248 ... 255
42 Bit field for devices which changed in the last step. Device 7 ... 0
43 ... 72 ...
73 Bit field for devices which changed in the last step. Device 248 ... 255
74 Color - Device 1+2
Bit 3 ... 0 Color Device 1, diag_pc.device[0].color
Bit 7 ... 4 Color Device 2, diag_pc.device[1].color
75 ... 200 ...
201 Device 255+256
Bit 3 ... 0 Color Device 255, diag_pc.device[254].color
Bit 7 ... 4 Color Device 256, diag_pc.device[255].color
Tab. 11-22.
