AS-i Safety Monitor for 2 AS-i circuits
Diagnostics for AS-i Monitor and networking using AS-i Master
Finally following in channel 3 is the collective information for the colors of the de-
vices in the release circuits.
Then the individual information is listed.
Channels 1 and 2 describe the states of the respective release circuits (OSSD’s)
of the Safety Monitor. For status codes and colors see section
Channel 3 contains information as to whether there are warnings or faults in a re-
lease circuit for one or more of the devices associated with this release circuit.
The information is as follows:
EF
Ground fault
There is a ground fault
1: There is a ground fault
0: There is not a ground fault
DA
Duplicate
address
There is a duplicate address
1: Duplicate address on AS-i
0: No duplicate address on AS-i
GN
Green
Errorless or nearly errorless communication
Less than 1% telegram repetitions on AS-i
YE
Warning
More frequent repetitions which need to be clarified depend-
ing on the application
1% - 5% telegram repetitions on AS-i
RD
Fault
Serious faults
Over 5% telegram repetitions on AS-i
UA
UAS-i
The AS-i voltage is sufficient
1: Voltage is sufficient
0: Voltage is not sufficient
AU
AUX 24 V
The 24 V for supplying the safe outputs is present
1: 24 V for supplying the safe outputs is present
0: 24 V for supplying the safe outputs is not present
Tab. 11-7.
YF
Yellow flashing
At least one of the devices associated with this release cir-
cuit is in the yellow flashing state
RF
Red flashing
At least one of the devices associated with this release cir-
cuit is in the red flashing state
Tab. 11-8.
