General
2. General
2.1 Product information
This system manual applies to the following Euchner GmbH + Co. KG equipment:
The AS-i Safety Monitor in a stainless steel enclosure is an E-STOP switching de-
vice which monitors safety configured slaves and correct function of the network.
The safety unit provides 4 inputs which can be defined as either EDM or as
START inputs.
The unit features two hierarchically equal AS-i circuits and four output switching
elements (two safety relays and two semiconductor outputs).
Features:
• Greater computing power to allow more function modules
• Graphical display for better diagnostics
• Optional storing of configuration data on an interchangeable memory card.
• EDM & START inputs can be defined freely
AS-i Safety Monitor for 2 AS-i circuits
RS 232 diagnostic port 103303
Tab. 2-1.
Functions of the device
Devi
ce
OSSDs AS-
i
Diag
no
stics
in
terface
Sem
icon
duct
o
r
ou
tp
ut
s
SaW
ou
tp
uts
Safe
ty relays
Safe
ty de
vices
103303 16 2 RS 232 2 16 2 256
Tab. 2-2.
Caption
OSSDs: number of release circuits
16: safety unit generates 16 independent switching signals
AS-i: number of AS-i circuits
2: safety unit functions with two equal AS-i circuits
Diagnostics interface: type of diagnostic port
Semiconductor
outputs:
number of semiconductor outputs:
SaW outputs: number of SaW outputs
Safety relays: number of safety relays
Safety devices: number of safety devices
Tab. 2-3.
