AS-i Safety Monitor for 2 AS-i circuits
Operation in advanced display mode
9.3.2 SAFE OUTPUT CH (channels for the release circuits)
Main Menu || AS-I SAFETY || SAFE OUTPUT CH ||
In this menu you can read off the status of the 16 release circuits.
9.3.3 SAFE COUPLING (optional menu)
Main menu || AS-I SAFETY || SAFE COUPLING ||
On the 2
nd
AS-i circuit up to two safe AS-i slaves (coupling slaves) can be creat-
ed which represent the states of the first two release circuits.
After entering the address (using the arrow keys) and confirming (with OK), the
display changes from ENABLE to DISABLE. Selecting DISABLE sets the address
to “00”.
For additional information refer to .
9.3.4 START/STOP (changing the Monitor mode)
Main Menu || AS-I SAFETY || START/STOP ||
SAFE OUTPUT
CHANNELS
CH 1: ON
CH 2: OFF
...
CH 16: OFF
SAFE COUPLING
ON CHANNEL 2
Information!
This menu is only displayed if there are no coupling slaves in the configuration.
SAFE COUPLING
ON CHANNEl 2
START/STOP
ENTER PIN
0000
OK
