AS-i Safety Monitor for 2 AS-i circuits
Diagnostics for AS-i Monitor and networking using AS-i Master
Subject to reasonable modifications due to technical advances Id.-No.: 103336 Issue date - 24.10.2008 EUCHNER GmbH + Co. KG 83
Kohlhammerstraße 16 • D-70771 Leinfelden-Echterdingen Tel. +49/711/75 97-0 • Fax. +49/711/753316
11.4.2.1 Status codes for the release circuits (OSSD)
11.4.2.2 Transparent output data
The transparent output data are available there to the safe unit as non-safe addi-
tional bits, for example for Start keys.
11.4.3 Acyclical data
Vendor Specific Object 1 – Analyzer status AS-i Circuit 1
Read only.
This object contains a bit pair for all 62 possible slaves which represents the sta-
tus of the slaves at this address:
Information!
Monitors supporting less than 8 release circuits set all non-present release circuits to
“gray”.
Code bit [3..0] Status / color Description
0 continuous green Output on
1 flashing green Wait time for Stop 1 in effect
2 continuous yellow Startup / restart active
3 flashing yellow External test required / acknowledgement /
Turn-on delay active
4 continuous red Output off
5 flashing red Fault
6 gray or off Output not assigned
7 ... F reserved
Tab. 11-9.
Ch
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 reserved Start2 EDM 2 Start1 EDM 1
Tab. 11-10.
Bit Lamp color
11 red
10 yellow
01 green
00 no slave
Tab. 11-11.
