AS-i Safety Monitor for 2 AS-i circuits
Electrical connection
Subject to reasonable modifications due to technical advances Id.-No.: 103336 Issue date - 24.10.2008 EUCHNER GmbH + Co. KG 37
Kohlhammerstraße 16 • D-70771 Leinfelden-Echterdingen Tel. +49/711/75 97-0 • Fax. +49/711/753316
7.8.3 Buttons
The buttons are used for the following:
For additional information see:
•
•
•
⇑
Navigation in extended mode
⇓
OK Change to extended mode
ESC/Service For teaching the code table for a new safe slave, when exactly one
safe slave is being replaced, and for unlocking the Safety Monitor.
This button is also used to exit extended mode.
