AS-i Safety Monitor for 2 AS-i circuits
Operation in advanced display mode
This menu shows the status of the safety AS-i safe slaves and the diagnostics for
the integrated Safety Monitor for each release circuit separately.
9.4.3.2 LAST DIAGNOSIS
Main Menu || DIAGNOSIS || MONITOR || SAFETY MONITOR || LAST DIAGNOSIS ||
SAFETY MONITOR
DIAGNOSIS
CH1.: ON
...
ASI 1
SLAVES
| 1-XX
2-RX | 3-RR
4- | 5-
....
A COLOR
32 RED
....
HELP:
X CODE OK
R RELEASED
A DEVICE ADR.
COMPLETE: The complete diagnostic is read out.
DIAG INDEX: The diagnostic is shown as it was configured under the
"device_Index_Assignment" in ASIMON.
Information!
If the diagnosis is read using DIAG INDEX, the device count begins at 0, otherwise at
32!
SAFETY MONITOR
DIAGNOSIS
LAST DIAGNOSIS
VIEW CONFIG
