4
Operation
79
Studio Daylight and Studio Tungsten
The Studio profile allows quick adjustment of Intensity. The Studio profile can be operated
in a stand-alone mode from the user interface or can be controlled via DMX.
Operation From Home Status Screen (Studio Standalone)
When operating without an external control signal, the intensity of the white light can be
adjusted immediately and directly by pressing the UI buttons on the fixture while on the
home screen.
Figure-4.46 Studio Status Home Screen.
•
To adjust the Intensity, press [
] and then [
]or [
]. The range is 0 to 100%.
•
To return to the Main Menu, press [
].
•
To return to the Studio status screen, from the Main Menu, press [
], [
], or allow
the UI to time out and automatically return to the status screen.
Studio DMX Control
When controlled via DMX, the channels adjust the following.
Channel
Output
1
Intensity (Brightness)
2
Strobe
3
Fan (D60 only)
Studio
Intensity
:
100%
System OK
1/3 Intensity
STUDIO MODE
