70 Desire Series v1.6.0 User Manual
Figure-4.33 Current DMX In Screen with Dynamic Values.
Step 3: Press [ ] or [ ] to scroll through the channels. Arrows on the left indicate that
you can scroll up or down.
Step 4: Press [ ] to return to the Diagnostics screen.
Network Statistics
The Network Statistics screen displays the statistics of the network. The DMX input values
dynamically change. This screen is read-only.
Step 1: On the Diagnostics screen, scroll to Network Statistics.
Step 2: Press [ ].
When you access the screen, the dynamic values start at 0 and continue to
increase.
Figure-4.34 Network Statistics Screen with Dynamic Values.
Step 3: To reset the counters, press [ ].
Step 4: Press [ ] to return to the Diagnostics screen.
Current DMX In
DMX Ch Level
2 107
3 14
4 82
5 0
G O R A O R I
11 02 00 10 00 00 01
DMX channel DMX value
Brightness LED series
Diagnostics
Breaks: 15490
Network Statistics
Overruns: 0
Received: 47835
Bad Starts: 0
DMX Starts: 27120
RDM Starts: 0
