46 Desire Series v1.6.0 User Manual
Home Screen Displays
Depending on the fixture settings, the following are displayed in the system message area
on the respective home (status) screens.
Vivid, Lustr+, Fire and Ice, Studio HD
Studio Daylight and Studio Tungsten
Profile (Vivid, Lustr+, Fire and Ice, Studio HD)
The control profile defines the number and control parameter assignments of input
channels for intensity and color-control. For more information, see Profiles, page 31 .
Profile (Studio Daylight and Studio Tungsten)
The control profile for Studio Daylight and Studio Tungsten includes only the Direct option.
The first channel of DMX control adjusts fixture Intensity from 0 to 100%. For more
information, see Studio Daylight and Studio Tungsten Profiles, page 35 .
Output Setting
Output is the way and amount to which the fixture constrains the overall power going to the
LED array, which determines how consistent the fixture’s brightness may be. For more
information, see Output, page 54 .
Dimming Curve
Dimming curve is the way that the fixture responds to changes in the control signal for
overall intensity. For more information, see Curve, page 55
Red Shift
Red shift replicates the warming of an incandescent filament’s color temperature change
as it dims. For more information, see Red Shift, page 57 .
Strobe
Strobe flashes the output of the LED array. For more information, see Strobe, page 51 .
Parameter Stage XT Arch High Impact Studio General
Profile HSI HSI RGB Studio
Direct Control
(Dir)
Output Setting
Regulated
(Reg) Protected
(Prt) Boost
(Bst) Regulated
(Reg) Regulated
(Reg)
Dimming Curve
Incandescent
(Incd) Standard
(Stnd) Quick
(Qik) Linear
(Lin) Standard
(Std)
Red Shift (RS) Disabled Disabled Disabled Disabled Disabled
Strobe (Str) On On On On On
Parameter Studio Stage Single Channel
Profile Direct Direct Direct
Output Setting Regulated (Reg) Regulated (Reg) Regulated (Reg)
Dimming Curve Linear (Lin) Incandescent (Incd) Standard (Std)
Strobe (Str) On On Off
Fan Control (D60 only) DMX DMX Automatic (Auto)
