Desire Series v1.6.0 User Manual
Quick Setups (Studio Daylight and Studio Tungsten)
Step 1:
On the Main Menu, scroll to Quick Setups.
Step 2:
Press [
].
Step 3:
Scroll to the desired setup and then press [
].
An asterisk (*) next to the setup name indicates that setup is active.
Step 4:
Press [
] to return to the home screen.
The top line of the home screen displays the name of the active setup.
XT Arch
Outdoor (D40XT only) and extreme
environments:
Longevity and reliability in applications
with limited access.
High degree of output consistency and
protection against temperature swings.
HSI
• Standard dimming curve
• Protected output for high-heat
environments
• Reduced overall brightness
• White point: 3200K
High Impact
Concerts and High Impact lighting:
Enables quickest response, simple RGB
control and strobe channel for maximum
effect usage.
RGB
• Quick dimming response
• Boosted output for maximum intensity
• Reduced consistency of output
• White point: 5600K
Studio
Video or film lighting:
Enables quick, comprehensive control of
white light via DMX or the fixture’s
onboard user interface.
High-quality white-light output.
Studio
• Linear dimming curve
• Regulated output for brightness
consistency
• Variable white point 2700-6500K
• Variable green/magenta balance (tint)
The Studio Quick Setup is operational in
all fixtures for excellent white light
performance. It is the default setting for
Studio and Studio XT fixtures. In addition,
Studio Quick Setup enables stand-alone
operation from the User Interface on the
back of the fixture if no console is present.
For more information, see
.
Quick Setup
Description
Control
Channels
Features
Studio
Video or film:
The default setting for Studio Daylight,
Studio Tungsten, and Studio HD fixtures.
Studio Quick Setup enables stand-alone
operation from the User Interface on the
back of the fixture if no console is present.
The fixture returns to the General setup
after a reset. For more information, see
3 –
Intensity,
Strobe, Fan
Control
(D60 only)
• Linear dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Stage
Theatrical lighting:
Behaves like a theatrical fixture in control
and dimming performance.
3 –
Intensity,
Strobe, Fan
Control
(D60 only)
• Incandescent dimming curve
• Regulated output for brightness
consistency
• Strobe enabled
Single
Channel
Architectural installations:
Most streamlined settings for applications
with limited control options.
1 – Intensity
• Standard dimming curve
• Regulated output for brightness
consistency
• Automatic fan control (D60 only)
Quick Setup
Description
Profile
Features
