H-2

95-8526

14.2

conFiGUrAtion AnD operAtion
Configuration of the EQP Eclipse is accomplished using Det-Tronics Safety System Software (S3) that is running on the

EQP Operator Interface Station (OIS).

onBoArD hArt port
The on-board HART port is functional on the EQP Eclipse, however, it should not be used for device configuration

purposes. All EQP device configuration should be performed using the S3 program.

MUlti-coloreD leD
Operation of the status indicating LED is identical to all other PIRECL versions.

reMote cAliBrAtion option
Operation of the remote calibration option is identical to all other PIRECL versions.

AnAloG oUtpUt
A 4-20 mA analog current output is not available with EQP PIRECL.

rs-485 coMMUnicAtion
RS-485 communication is not available with EQP PIRECL.

cAliBrAtion roUtine
The calibration procedure for the EQP PIRECL (normal and zero calibration) is identical to all other PIRECL versions.

NotE

For complete information regarding installation, configuration or operation of the Eagle Quantum Premier system,
refer to form 95-8533 (Eagle Quantum Premier hardware manual) or form 95-8560 (Safety System Software
manual).

eclipse operAtion With eAGle QUAntUM preMier

Table H-2—Typical update Rate for PIREcL in an EQP System

Field Device

transmit time to controller (sec)

PIRECL

Gas Alarms

Gas Level

Immediate

1

Device Fault

1
