background image

25

95-8526

14.2

tRoublEShooting

A Fault status is indicated by a yellow LED and also by

the 4-20 mA outout. Refer to Table 6 to identify the fault

type using the 4-20 mA output. (The operator must know

which fault signaling mode has been programmed.)

Refer to Table 7 for assistance in correcting malfunctions

with the PointWatch Eclipse Detector.

dEvicE REpaiR and REtuRn

The Pointwatch Eclipse IR Hydrocarbon Gas Detector is

not designed to be repaired in the field. If a problem

should develop, first carefully check for proper wiring,

programming and calibration. If it is determined that the

problem is caused by an electronics failure, the device

must be returned to the factory for repair.

Prior to returning devices or components, contact the

nearest local Detector Electronics office so that a Service

Order number can be assigned. A written statement

describing the malfunction must accompany the returned

device or component to expedite finding the cause of the

failure.

Return all equipment transportation prepaid to the factory

in Minneapolis.

table 6—using the 4-20 ma output Level to Identify a Fault Condition

Condition

eclipse fault Mode

pir9400 fault Mode

User Defined fault Mode

Gas Level (-10% to 120% Full scale)

2.4 to 20.5

2.4 to 20.5

2.4 to 20.5

Warm-up

1.00

0.00

Warm-up

Reference Sensor Saturated

1.00

0.20

General Fault

Active Sensor Saturated

1.00

0.40

General Fault

Calibration line active on power-up

1.00

0.60

General Fault

Low 24 volts

1.00

0.80

General Fault

Low 12 volts

1.00

1.20

General Fault

Low 5 volts

1.00

1.20

General Fault

Dirty Optics

2.00

1.00

Blocked Optics

Calibration Fault

1.00

1.60

General Fault

Calibration complete

1.00

1.80

Calibration

Span calibration, apply gas

1.00

2.00

Calibration

Zero calibration in progress

1.00

2.20

Calibration

Negative signal output fault

1.00

2.40

General Fault

Flash CRC

1.00

1.20

General Fault

Ram Error

1.00

1.20

General Fault

EEPROM Error

1.00

1.20

General Fault

IR Source Failure

1.00

1.20

General Fault
