F-6

95-8526

14.2

DiAGnostics/service MenU
The specific diagnostic and/or service functions available are:

1 test Device

1 Self-test. Internal tests are performed and any problems are reported in

xmtr flt 1 and xmtr flt 2.

2 Response Test. The analog output is held at 4 mA to prevent the alarm relays

from activating when gas is applied. Gas response is indicated

by the PV.

3 Reset. Latched relay outputs are reset.

2 loop test
This test allows the operator to manually set the analog signal output to a selected constant

value.

3 calibration
This menu option initiates the calibration routine and is used to set device calibration preferences.

Calibration Submenus include:

1 Zero Trim. The current sensor input is used as the new zero reference.

2 Calibrate Sensor. This is the command used to calibrate the Eclipse Detector. Submenus include:

1 Calibrate. Zero and span calibrations are performed.

2 Cal Concentration. The output will be set to this value when gas is applied during calibration.

3 Cal Gas

4 Gas Type. Submenu includes optional gases:

Methane

Propane

5 Calibration Type. Submenu includes options:

Standard

Cuvette

6 Cuvette Length (in millimeters)

3 Calibration Date (CalDate). Shows date of last calibration

4 D/A trim (internal use only).

4 status
This menu option shows extensive status information about the detector. Data available includes:

1 Reference xxxx (output value of the reference sensor).

2 Snsr temp xxxx (temperature of the sensor that is making the process measurement).

3 Operating mode (calibration, normal, reset)

4 Calibration

5 xmtr flt 1. Xmtr flt and xmtr status provide status information relating to failures, warnings and status

of processes.

6 xmtr flt 2

7 xmtr status 1

8 xmtr status 2

1 Test Device

2 Loop Test

3 Calibration

4 Status

5 History
