background image

23

95-8526

14.2

4. Return to Normal is complete when:

A. The onboard LED changes from “off” to steady

green.

B. The LED within the PIRTB (if used) turns off.
C. The Eclipse current output returns to 4 mA after

detected calibration gas level drops below 5%

LFL or the calibration abort signal is provided.

tiMe oUt
If calibration is not completed within 10 minutes, a

calibration-failed fault is generated, and the unit returns to

normal operation using the previous calibration values.

NOTE

Under normal conditions, span calibration is
typically completed in 3 minutes or less.

Calibration abort
Calibration can be aborted at any time after zero

calibration is completed. This is done by activating the

onboard or PIRTB magnetic switch, or by a command

from the HART, MODBUS or EQP interface. If calibration

is terminated, the new zero point is retained, and a zero

calibration code is saved in the calibration history buffer.

The unit will immediately return to normal operation.

table 5—Quick Reference Guide for Zero only Calibration Procedure using Magnetic Switch

table 4—Quick Reference Guide for normal Calibration Procedure using Magnetic Switch

Description

indicating leD

(on-board/pirtb)

Current output

(default setting)

operator action

Normal-ready to calibrate

steady green/off

4 mA

Purge with clean air if required

Initiate Calibration

steady red/on-steady

1 mA

Apply Magnet for 2 seconds min.

Zero Calibration complete

flashing red/on-flashing

1 mA

Apply Calibration Gas to device

Span Calibration in progress

flashing red/on-flashing

1 mA

Continue cal gas flow

Span Calibration complete

off/on-steady

1 mA

Remove Calibration Gas

Output Returns to Normal

steady green/off

4 mA

Calibration Completed

Normal Operation

steady green/off

4 mA

None

Description

indicating leD

(on-board/pirtb)

Current output

(default setting)

operator action

Normal-ready to calibrate

steady green/off

4 mA

Purge with clean air if required

Initiate Calibration

steady red/on-steady

1 mA

Apply Magnet for 2 seconds min.

Zero Calibration complete

flashing red/on-flashing

1 mA

Re-initiate magnetic switch

to terminate calibration

Return to Normal Mode

steady green/off

4 mA

Zero Calibration Completed
