A-1

95-8526

14.2

Appendix A

FM ApprovAl Description

The following items, functions and options describe the FM approval.

ApprovAl
PointWatch Eclipse

®

Infrared Hydrocarbon Gas Detector, Model PIRECL Series.

Explosion-proof for Class I, Division 1, Groups B, C, & D (T4) Hazardous (Classified) Locations per FM 3615,

With intrinsically safe output for HART communication in accordance with control drawing 007283-001.

Non-incendive for Class I, Division 2, Groups A, B, C & D (T3C) Hazardous (Classified) Locations per FM 3611.

Tamb = –40°C to +75°C. Acidic atmospheres excluded. Conduit seal not required.

Performance verified for 0 to 100% LFL Methane-in-air atmospheres per FM 6310/6320 and ANSI 12.13.01.

Performance verified for 0 to 100% LFL Propane-in-air atmospheres per FM 6310/6320 and ANSI 12.13.01.

Performance verified for 0 to 100% LFL Ethylene-in-air atmospheres per FM 6310/6320 and ANSI 12.13.01.

Performance verified for 0 to 100% LFL Butane-in-air atmospheres per FM 6310/6320 and ANSI 12.13.01.

NOTES

Approval of the Model PIRECL does not include or imply approval of the apparatus to which the detector may
be connected and which processes the electronic signal for eventual end use. In order to maintain an approved
system, the apparatus to which the detector is connected must also be approved.

This Approval does not include or imply Approval of the communications protocol or functions provided by the
software of this instrument or the communications apparatus or software connected to this instrument.

RESPONSE TIME (Average

*

in Seconds, with Weather Protection Baffle Installed, and 100% LFL Applied)—

Gas

Baffle

t50

t60

t90

Methane

Without Hydrophobic Filter

4.5

4.9

6.8

With Hydrophobic Filter

4.7

5.0

7.6

Propane

Without Hydrophobic Filter

5.2

5.6

7.5

With Hydrophobic Filter

5.3

5.6

8.1

Ethylene

Without Hydrophobic Filter

4.9

5.5

6.6

With Hydrophobic Filter

4.2

4.5

10.1

Butane

Without Hydrophobic Filter

5.1

5.4

7.6

With Hydrophobic Filter

5.8

6.1

8.9

*

Average of three consecutive trials, with the minimum and maximum response times no greater
than ±2 seconds from the average indicated response time.

NOTE: Add 2 seconds to response time for EQP compatible models.
