background image

A-2

95-8526

14.2

AccuRAcy—

±3% LFL from 0 to 50% LFL, ±5% LFL from 51 to 100% LFL

(at room ambient temperature, +23°C).

NOTE

Product operates properly with 5 watt walkie talkie keyed at 1 meter.

other GAses
The Pointwatch Eclipse

®

is provided with field-selectable “standard gas” signal processing program settings for linear

measurement of methane, propane, ethylene, and butane gases. This means that the Eclipse is capable of providing

an analog signal output that is directly proportional to the % LFL concentration for these gases, provided the proper

gas setting has been selected, and the Eclipse has been calibrated with the proper calibration gas type. The Eclipse

is performance certified for detection of methane, propane, ethylene, or butane, and is shipped from the factory

calibrated and set for the customer’s choice of one of these gases. Digital communication (such as HART) is required

to confirm the current setting and change it if required. In addition to the gases listed above, the Eclipse is capable of

detecting and measuring many other hydrocarbon gases and vapors, with settings provided for gases such as ethane

and propylene. For detection of other commonly encountered gases where specific gas settings are not provided, one

of the standard settings will usually suffice. Please consult the factory for details.

ApproveD Accessories

part number

Description

007355-001

Q900A Duct Mount Kit, Standard

009931-001

Q900c Duct Mount Kit, Marine

007525-003

Direct Duct Mount Kit, Stainless Steel, Vertical

007525-004

Direct Duct Mount Kit, Aluminum, Vertical

007525-005

Direct Duct Mount Kit, Stainless Steel, Horizontal

007525-006

Direct Duct Mount Kit, Aluminum, Horizontal

007529-XXX

Direct Duct Assembly w/PIREcL, Kit – This part number

consists of several combinations of approved PIREcL detectors

and Direct Duct Assemblies (007525-003-006).

006468-006

Gas calibration Kit, 50% Butane

006468-003

Gas calibration Kit, 50% Ethylene

006468-014

Gas calibration Kit, 50% Methane (2.2% Vol.)

006468-914

Gas calibration Kit, 50% Methane (Russian certified, 2.2% Vol.)

006468-001

Gas calibration Kit, 50% Methane (2.5% Vol.)

006468-906

Gas calibration Kit, 50% Methane (Russian certified, 2.5% Vol.)

006468-004

Gas calibration Kit, 50% Propane (1.1% Vol.)

006468-015

Gas calibration Kit, 50% Propane (0.85% Vol.)

006468-915

Gas calibration Kit, 50% Propane (Russian certified)

102740-002

calibration Magnet

103922-001

475 HART Field communicator

103922-002

475 HART & Foundation Fieldbus Field communicator

NOTE

Refer to the appropriate instruction manual for complete information regarding the following devices:

Q900A - 95-8537

Q900C - 95-8640

Direct Duct Mount Kits - 95-8557
