G-3

95-8526

14.2

Device configuration: (read/Write)
This area of memory holds field adjustable parameters for the device. The Hart configuration changed bit will be set

on writes to this area.

eclipse Device configuration

Description

Address

value

Modbus Polling Address

40101

1..247

Baud Rate Code

40102

See Codes

Parity Code

40103

See Codes

Gas Type

40104

See Codes

Calibration Gas Type

40105

See Codes

Calibration Method

40106

See Codes

Calibration Cuvette Length

(1.0 to 150.0 mm)

40107

Float LSW

40108

Float MSW

Analog Fault Code

40109

See Codes

4 to 20 Range

(20 to 100% LEL)

40110

Float LSW

40111

Float MSW

Cal Gas Concentration

(20 to 100% LEL)

40112

Float LSW

40113

Float MSW

Warmup Fault Level

(0.0 to 24.0 mA)

40114

Float LSW

40115

Float MSW

Blocked Optics Fault Level

(0.0 to 24.0 mA)

40116

Float LSW

40117

Float MSW

Calibration Current Level

(0.0 to 24.0 mA)

40118

Float LSW

40119

Float MSW

General Fault Current Level

(0.0 to 24.0 mA)

40120

Float LSW

40121

Float MSW

Volume at LEL

(Special Gas Type)

40122

Float LSW

40123

Float MSW

Gas Coefficient a

(Special Gas Type)

40124

Float LSW

40125

Float MSW

Gas Coefficient b

(Special Gas Type)

40126

Float LSW

40127

Float MSW

Gas Coefficient c

(Special Gas Type)

40128

Float LSW

40129

Float MSW

Gas Coefficient d

(Special Gas Type)

40130

Float LSW

40131

Float MSW

Gas Coefficient e

(Special Gas Type)

40132

Float LSW

40133

Float MSW

Low Alarm Level

(5 to 60% LEL)

40134

Float LSW

40135

Float MSW

High Alarm Level

(5 to 60% LEL)

40136

Float LSW

40137

Float MSW

Low Alarm Latch

40138

See Codes

High Alarm Latch

40139

See Codes

Reserved

40140

NOTE

Refer to “Alarm Relays” in the
Specifications section of this manual for
important information regarding alarm
relays.
