Wrong – Det-Tronics PIRECL Infrared Hydrocarbon Gas Detector PointWatch Eclipse User Manual
Page 19
17
95-8526
14.2
WRONG
HAZARDOUS LOCATION
NON-HAZARDOUS LOCATION
24 VDC +
24 VDC –
4-20 MA SIGNAL
24 VDC +
24 VDC –
4-20 MA SIGNAL
24 VDC +
24 VDC –
4-20 MA SIGNAL
24 VDC +
24 VDC –
+ 4-20 MA
– 4-20 MA
PIRECL
PIRECL
HART
COMMUNICATOR
HART
COMMUNICATOR
HART
COMMUNICATOR
HART
COMMUNICATOR
PIRTB
PIRTB
D2060
NOTE: THE TOTAL WIRING DISTANCE FROM THE HART COMMUNICATOR
THROUGH THE POINTWATCH ECLIPSE TO THE SIGNAL RECEIVER
MUST NOT EXCEED 2000 FEET (610 METERS).
CAL GAS
24 VDC, CAL
PIRECL
PIRTB
ISOLATED 4-20 MA
CAL GAS
PIRECL
PIRTB
NON-ISOLATED 4-20 MA
NON-ISOLATED 4-20 MA
NON-ISOLATED 4-20 MA
Figure 21—Remote Calibration Configuration options
