faUlt inDiCation
There are three modes of signaling faults using the 4-20

mA analog signal output:

Eclipse

(Factory default setting for units

manufactured after 1/1/2014)

PIR9400

(Used for retrofit applications of the

PIR9400 detector. Factory default setting

for units manufactured before 1/1/2014)

user Defined

Fault signaling mode can be selected using the HART or

MODBUS interface. Table 3 shows the current levels for

each fault mode.

eclipse fault Mode
Eclipse mode follows conventional fault signaling practice.

The current loop output indicates the presence of a fault,

but does not attempt to identify a specific fault with a

specific current output value. Identification of a specific

fault type is done through the HART Communicator or

MODBUS.

pir9400 fault Mode
This mode is provided for compatibility with existing

Det-Tronics PointWatch gas detectors. The fault and

calibration levels are identical to existing PIR9400 units,

which makes the Eclipse compatible with the U9500

Infiniti Transmitter. As with the PIR9400 detector, live

and suppressed “signal during calibration” modes are
available.

User Defined fault Mode
This mode is intended for users who wish to program

unique current levels for faults and calibration signals.

User defined current levels can be set from 0.0 to 24.0

mA. and can be programmed from HART or MODBUS

interfaces. Four unique current levels are available:

warm-up, general fault, calibration, and blocked optics.

table 3—output Levels of 4-20 ma Current Loop and Corresponding Status Indications

Condition

eclipse fault Mode

pir9400 fault Mode

User Defined fault Mode

Gas Level (-10% to 102.2% Full scale)

2.4 to 20.5

2.4 to 20.5

2.4 to 20.5

Warm-up

1.00

0.00

Warm-up

Reference Sensor Saturated

1.00

0.20

General Fault

Active Sensor Saturated

1.00

0.40

General Fault

Calibration line active on power-up

1.00

0.60

General Fault

Low 24 volts

1.00

0.80

General Fault

Low 12 volts

1.00

1.20

General Fault

Low 5 volts

1.00

1.20

General Fault

Dirty Optics

2.00

1.00

Blocked Optics

Calibration Fault

1.00

1.60

General Fault

Calibration complete

1.00

1.80

Calibration

Span calibration, apply gas

1.00

2.00

Calibration

Zero calibration in progress

1.00

2.20

Calibration

Negative signal output fault

1.00

2.40

General Fault

Flash CRC

1.00

1.20

General Fault

Ram Error

1.00

1.20

General Fault

EEPROM Error

1.00

1.20

General Fault

IR Source Failure

1.00

1.20

General Fault
