SECTION 3 - ATTACHMENTS
8990462 644E-42,944E-42 81
FIGURE 3-12. 10 FT TRUSS BOOM WITH WINCH (Prior to SN 0160037794)
ITEM PART NUMBER QTY DESCRIPTION REV
7301179 1 10 FT TRUSS BOOM WITH WINCH ASSY, (includes all items) F
1 1012355 1 WIRE ROPE ASSY, 3/8X75
2 10721557 3 WIRE CLIP, 3/8
3 10721556 1 THIMBLE, 3/8
4 10267585 1 HOOK ASSY
5 4110412 2 CAPACITY DECAL
6 8406302 2 HOSE CLAMP
7 10727770 1 HYDRAULIC WINCH WITH BRAKE
7 70021573 1 WINCH MOTOR
8 2110810 2 CONNECTOR
9 2172108 2 ELBOW, 90, (swivel nut)
10 2717093 2 HOSE ASSY
11 91403414 1 QUICK DISCONNECT NIPPLE
12 8420053 1 DUST CAP, #8
13 8420055 1 DUST PLUG, #8
14 91403413 1 QUICK DISCONNECT COUPLER
15 2130808 2 ELBOW, 90
16 10700484 6 HEX HD CAPSCREW, 1/2-20X2-1/4, GR8
17 11419080 10 HEX LOCKNUT, 1/2-20 (644E Prior to SN 0160032221; 944E
Prior to SN 0160032117)
17 11419080 6 HEX LOCKNUT, 1/2-20 (644E SN 0160032221 to Present; 944E
SN 0160032117 to Present)
18 7301191 1 10 FT TRUSS BOOM
19 4110252 4 PINCH POINT/ENTANGLEMENT HAZARD DECAL
20 10727327 1 Sheave
21 8382017 1 PINTLE HOOK (644E Prior to SN 0160032221; 944E Prior to SN
0160032221)
23 11170040 1 LOCKNUT, 1/4-28
24 11160110 1 STRAIGHT GREASE FITTING, 1/4-28
25 10125085 1 PIN
26 11045080 1 HEX HD CAPSCREW, 1/4-28X2, GR5
27 4110422 2 DANGER SWINGING LOADS DECAL
28 4110424 1 HOSE ROUTE WARNING DECAL
29 N.S.S. 1 SN PLATE
