SECTION 1 - FRAME AND ATTACHING PARTS
8990462 644E-42,944E-42 19
FIGURE 1-3. MAIN FRAME COMPONENTS (644E SN 160048717 to Present, Including 0160045421;
944E SN 160041827 to Present)
ITEM PART NUMBER QTY DESCRIPTION REV
1001143083 Ref FRAME INSTALLATION, (644E), (not available to order, see items
1 thru 6 & 8 thru 10 for service) A
1001120707 Ref FRAME INSTALLATION, (944E), (not available to order, see items
1 thru 10 for service) A
1 Ref TRANSFER CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
2 7300726 Ref FRAME LEVEL INSTALLATION, (not available to order, see items
101 thru 111 for service) E
3 7300727 Ref STABIL-TRAK CYLINDER INSTALLATION, (not available to
order, see items 102 thru 111 & 151 for service) D
4 7300753 Ref TRANSFER CYLINDER STOP INSTALLATION, (not available to
order, see items 201 & 202 for service) AD
5 7300859 Ref TRANSFER CYLINDER MOUNTING INSTALLATION, (not
available to order, see items 251 & 252 for service) AD
6 7301097 Ref FRAME COVER INSTALLATION, (not available to order, see
items 301 thru 304 for service) D
7 7301146 Ref COUNTERWEIGHT INSTALLATION, (944E), (not available to
order, see items 351 thru 354 for service) B
8 7301222 1 HOSE TRAY ASSEMBLY E
8 7301868 AR 1IN ADHESIVE TAPE
9 N.S.S. 1 WELDMENT
10 Ref TRANSFER CARRIAGE INSTALLATION, (See BOOM SECTION
for Breakdown )
101 Ref FRAME LEVEL CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
102 7137142 2 PIN
103 7139886 2 PIN SPACER
104 7301149 2 PIN
105 8050001 2 BEARING
106 8305654 2 HEX NUT, M8X1.25
107 8310656 2 HEX HD CAPSCREW, M12X60, GR8.8, (torque to 59-106 Nm/44-
78 lb-ft)
108 8310424 2 HEX HD CAPSCREW, M8X90, GR8.8, (torque to 17-31 Nm/13-23
lb-ft)
109 8310625 2 HEX NUT, M12X1.75
110 8310657 2 WASHER, 12mm
111 8520001 2 GREASE FITTING
151 Ref STABIL-TRAK CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
201 7300754 2 TC STOP BLOCK
202 8321701 4 HEX HD CAPSCREW, M20X150, GR8.8
251 7300503 1 PIN
252 8630026 2 RETAINING RING
301 3575924 1 FRAME COVER PLATE
302 8307220 4 WASHER, 12mm
303 8310625 4 HEX NUT, M12X1.75
304 10704216 4 HEX HD CAPSCREW, M12X110, GR8.8
351 1001094782 1 COUNTERWEIGHT, (944E)
352 8305655 4 HEX NUT, M20X2.5, (torque to 295-530 Nm/218-391 lb-ft), (944E)
353 8310426 8 WASHER, 20mm, (944E)
354 8321701 4 HEX HD CAPSCREW, M20X150, GR8.8, (944E)
401 Ref ENGINE POD INSTALLATION, (See ENGINE POD INSTALLATION
