SECTION 8 - HYDRAULIC CIRCUITS
8990462
644E-42,944E-42
401
FIGURE 8-10. FRAME LEVEL/STABIL-TRAK (SN 17569 through 18460)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
2110606
8
ADAPTER
2
2716963
1
HOSE ASSEMBLY
3
2716966
1
HOSE ASSEMBLY
4
2717060
1
HOSE ASSEMBLY
5
7300499
1
HOSE ASSEMBLY
6
2716950
1
HOSE ASSEMBLY
7
2717058
1
HOSE ASSEMBLY
8
2717059
1
HOSE ASSEMBLY
9
2717057
1
HOSE ASSEMBLY
10
8770111
1
SWIVEL RUN TEE
11
2717070
1
HOSE ASSEMBLY
12
2130606
2
ELBOW, 90
13
2220218
1
REDUCER/EXPANDER, #10-6
14
2717169
1
HOSE ASSEMBLY
15
2717172
1
HOSE ASSEMBLY
16
2717171
1
HOSE ASSEMBLY
17
7300467
1
TUBE ASSEMBLY
18
7300468
1
TUBE ASSEMBLY
19
7300469
1
TUBE ASSEMBLY
20
7300949
1
TUBE ASSEMBLY
21
7300948
1
TUBE ASSEMBLY
22
2717173
1
HOSE ASSEMBLY
23
2717000
1
HOSE ASSEMBLY
24
8902862
2
CHECK VALVE, .054
25
8770140
2
ELBOW, 45
26
8303541
11
HEX HD CAPSCREW, M6X35, GR8.8
27
8750020
11
TWIN COVER PLATE
28
8750018
11
TWIN CLAMP SET, .375
29
8303544
2
HEX HD CAPSCREW, M6X20, GR8.8
30
8770154
1
ELBOW, 90
31
2130606
1
ELBOW, 90
32
Ref
HOSE ASSEMBLY, (order items 11 & 1)
33
Ref
HOSE ASSEMBLY, (order items 14 & 1)
34
Ref
FRAME LEVEL CONTROLLER, (See CONTROL SECTION for
Breakdown)
35
Ref
FRAME LEVEL CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
36
Ref
STABIL-TRAK CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
37
8526007
AR
LOCTITE 242, (apply to item 29)
38
Ref
MANIFOLD, (See PUMP, SUCTION AND RETURN for Breakdown)
39
Ref
MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
40
8750044
11
RAIL NUT, M6
