SECTION 10 - ELECTRICAL
8990462 644E-42,944E-42 535
FIGURE 10-5. POWER COMPONENTS 644E (SN 0160003690 through 0160043356, Including 19557,
20118 and 0160003489)
ITEM PART NUMBER QTY DESCRIPTION REV
1 4922986 1 POWER HARNESS (SN 0160003690 through 0160014863)
1 4923359 1 POWER HARNESS (SN 0160014889 through 0160043356)
2 8584001 AR TIE WRAP
3 7300853 1 RELAY MOUNTING BRACKET
4 8307220 4 PLAIN WASHER, 12mm
5 8305044 3 HEX NUT, M12X1.75
6 10167789 1 3 POST WITH DIODE RELAY
7 8307219 2 PLAIN WASHER, 6mm
8 8303545 2 HEX HD CAPSCREW, M6X16, GR8.8, (torque to 7-12.5 Nm)
9 8307003 1 LOCKWASHER, #10
10 8305003 1 HEX NUT, #10-32
11 8307004 2 LOCKWASHER, 5/16
12 8305006 2 HEX NUT, 5/16-18, GR2
13 8305038 3 HEX NUT, M10X1.5
14 8307221 5 PLAIN WASHER, 10mm
15 8303777 2 HEX HD CAPSCREW, M10X35, GR8.8, (torque to 43 Nm)
16 6621412 1 STARTER TERMINAL, 90
17 8307023 2 SPRING LOCKWASHER, 10mm
18 8310650 2 LOCKWASHER, 12m, (external tooth)
19 7300344 1 NEGATIVE STARTER BUS BAR
20 8303533 1 HEX HD CAPSCREW, M12X20, GR8.8, (torque to 43 Nm)
21 8303528 1 HEX HD CAPSCREW, M8X65, GR8.8
22 8750025 1 TWIN COVER PLATE
23 8750024 2 TWIN CLAMP SET, 1.18 DIA
24 8750039 1 BOLT STACKING, METRIC
25 8750017 1 LOCKING PLATE
26 8750043 1 RAIL NUT, M8
27 7310012 1 FUSIBLE LINK ASSEMBLY
28 Ref ALTERNATOR, (See ENGINE AND ATTACHING PARTS SECTION
for Breakdown)
29 Ref STARTER, (See ENGINE AND ATTACHING PARTS SECTION for
Breakdown)
30 Ref FRAME GROUNDING HARDWARE, (See BATTERY AND
VEHICLE GROUND CABLES for Breakdown)
