SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
249
FIGURE 5-33. REAR AXLE - JOINT HOUSING (644E SN 0160039830 to Present, Including
0160036724, 0160036811, 0160036907 and 0160037012; 944E SN 0160040124 to Present, Including
0160034634, 0160036710, 0160036722, 0160036735 and 0160036738)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
70022237
1
JOINT HOUSING, (right side)
2
70022238
1
JOINT HOUSING, (left side)
3
70022223
4
ROLLER BEARING
4
1319447
4
SHAFT SEAL
5
70022240
4
BEARING PIN
6
1319464
16
HEX SCREW, M16X40
7
70022179
2
BUSHING
8
10731789
2
RETAINING RING
9
70022218
2
SHAFT SEAL
10
1321226
2
RETAINING RING
11
70022170
2
UNIVERSAL COUPLING DRIVE SHAFT ASSY, (includes items 12
thru 15) (Prior to SN 0160041827)
11
70022781
2
UNIVERSAL COUPLING DRIVE SHAFT ASSY, (includes items 12
thru 15) (SN 0160041827 to Present)
12
70021554
2
JOINT CROSS
13
70021553
1
CENTRAL PIECE (Prior to SN 0160041827)
13
70022782
1
CENTRAL PIECE (SN 0160041827 to Present)
14
70022187
1
FORK SHAFT
15
70022188
1
FORK SHAFT
16
80304173
2
SHAFT SEAL
17
1319472
4
ROLLER BEARING
18
70022208
16
HEX HD CAPSCREW, M14X70 (Prior to SN 0160041827)
18
70023405
16
HEX HD CAPSCREW (SN 0160041827 to Present)
19
70022234
16
CENTERING BUSHING
20
70022249
2
HUB
21
70022203
2
O-RING
22
70022230
20
WHEEL BOLT (Prior to SN 0160041827)
22
70023909
20
WHEEL BOLT (SN 0160041827 to Present)
23
Ref
WHEEL NUT, (See DRIVE TRAIN COMPONENTS for Breakdown)
24
Ref
SPRING WASHER, (See DRIVE TRAIN COMPONENTS for
Breakdown)
25
8036330
4
STOP SCREW, M14X1.5
26
1319477
2
HEX NUT, M14X1.5
