Page 359
SECTION 7 - CONTROLS
8990462
644E-42,944E-42
359
FIGURE 7-9. JOYSTICK CONTROL VALVE ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
8902330
1
JOYSTICK CONTROL VALVE ASSY, (includes all items)
B
1
8036621
1
HANDLE ASSY w/SWITCH, (includes item 2)
2
8036625
1
BUTTON COVER
3
8036622
1
JOINT ASSY, (includes item 4)
4
8036623
1
BOOT
5
8036624
4
CAPSULE ASSY, (includes item 6)
6
7029419
1
PLUNGER ASSY, (includes item 7)
7
8036620
1
PLUNGER SEAL KIT
8
Ref
VALVE BODY
