SECTION 10 - ELECTRICAL
8990462
644E-42,944E-42
543
FIGURE 10-8. OPEN CAB ELECTRICAL COMPONENTS (SN 17569 through 19041)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
Ref
OPEN CAB HARNESS, (not available to order, use 7300336 for
replacement)
2
8220362
1
FUSE/RELAY BOX, (See FUSES, RELAYS AND FLASHER BOX
for Breakdown)
3
8220357
2
CLEAR VES-PAC COVER
4
8220363
2
CIRCUIT BOARD, 3 DIODE
5
7301600
1
AUXILIARY HYDRAULIC DUMP VALVE HARNESS
6
8223050
1
AUXILIARY HYDRAULIC DUMP VALVE SWITCH
7
8305652
1
HEX LOCKNUT, M6X1
8
8310687
2
LOCKWASHER, 6mm, (external tooth)
9
8307219
1
PLAIN WASHER, 6mm, (metric)
10
8223241
1
BRAKE PRESSURE SWITCH
11
8584001
AR
TIE WRAP
12
6611172
1
GROUND CABLE, CAB TO CAB SUPPORT
13
8305654
2
HEX LOCKNUT, M8X1.25
14
8307222
2
PLAIN WASHER, 8mm
15
8310647
4
LOCKWASHER, 8mm, (external tooth)
16
8310683
2
HEX HD SELF TAPPING SCREW, 5/16-18X3/4
17
7301147
1
BUZZER BRACKET
18
8270627
1
ALARM BUZZER, 12V
19
8223054
1
PARK BRAKE SWITCH
20
8223071
1
TRANSMISSION DISCONNECT SWITCH
21
8223072
1
SELECTOR TRANSMISSION CONTROL, (includes attaching
hardware)
22
8720017
1
HORN BUTTON WITH COVER SWITCH
23
8220360
1
DASH PANEL
24
1101202
1
IGNITION SWITCH, (includes item 25)
25
1101203
1
IGNITION KEY, (set of 2 keys)
26
Ref
FUEL LEVEL SENDER, (See ENGINE AND ATTACHING PARTS
SECTION for Breakdown)
27
Ref
ECM INDICATOR SWITCH, (See CONTROLS SECTION for
Breakdown)
28
Ref
STABIL-TRAK SWITCH, (See CONTROLS SECTION for
Breakdown)
29
Ref
BRAKE SWITCH, (See OPTIONS SECTION for Breakdown)
30
Ref
PILOT SELECT VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
31
Ref
ACCUMULATOR CHARGE VALVE, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
32
Ref
DUMP VALVE, (See HYDRAULIC COMPONENTS SECTION for
Breakdown)
33
Ref
JOYSTICK CONTROL VALVE, (See HYDRAULIC CIRCUITS
SECTION for Breakdown)
