SECTION 9 - HYDRAULIC COMPONENTS
8990462 644E-42,944E-42 467
FIGURE 9-18. TRANSFER CYLINDER
ITEM PART NUMBER QTY DESCRIPTION REV
2716850 1 TRANSFER CYLINDER, (includes items 1 thru 16) AC
1 N.S.S. 1 WELDMENT TUBE
2 8036586 1 WELDMENT ROD
3 8036588 1 HEAD GLAND, (torque to 250-300 lb-ft)
4 8036587 1 ROD SPACER
5 8036589 1 PISTON
6 8035322 1 LOCKNUT, 1.50-12, (loctite and torque to 500-550 lb-ft)
7 Kit K1 1 WIPER SEAL
8 Kit K1 1 O-RING
9 Kit K1 2 LOCKING INSERT
10 Kit K1 1 DZR SEAL
11 Kit K1 1 PRECISION WEARBAND
12 Kit K1 1 BACKUP RING
13 Kit K1 1 O-RING
14 Kit K1 1 O-RING
15 Kit K1 2 PECISION WEARBAND
16 Kit K1 1 CAPPED T-SEAL
17 8526011 AR LOCTITE 271
K1 8036476 1 SEAL KIT, (includes items 7 thru 16)
