SECTION 8 - HYDRAULIC CIRCUITS
8990462
644E-42,944E-42
415
FIGURE 8-16. FRONT JOYSTICK
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
Ref
JOYSTICK CONTROL VALVE ASSY, (See CONTROLS SECTION
for Breakdown)
2
2110606
9
ADAPTER
3
8770111
2
SWIVEL RUN TEE
4
2716967
2
HOSE ASSEMBLY
5
2130606
3
ELBOW, 90
6
2716961
1
HOSE ASSEMBLY
7
2716964
1
HOSE ASSEMBLY
8
8770140
2
ELBOW, 45
9
7301005
1
TUBE ASSEMBLY
10
7301004
1
TUBE ASSEMBLY
11
2172106
1
ELBOW, 90, (swivel nut)
12
7301002
1
TUBE ASSEMBLY
13
7301003
1
TUBE ASSEMBLY
14
2110604
2
CONNECTOR
15
2130604
4
ELBOW, 90
16
2716960
1
HOSE ASSEMBLY
17
2716965
1
HOSE ASSEMBLY
18
2716962
1
HOSE ASSEMBLY
19
2716963
1
HOSE ASSEMBLY
20
8303544
4
HEX HD CAPSCREW, M6-1.00X20mm, PC8.8
21
4641316
1
CHECK VALVE
22
8307219
4
PLAIN WASHER, 6mm
23
Ref
SWIVEL RUN TEE, (See REAR JOYSTICK for Breakdown)
24
8526007
AR
LOCTITE 242, (apply to item 20)
25
Ref
MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
26
Ref
ACCUMULATOR CHARGE VALVE, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
27
Ref
PILOT SELECT VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
28
Ref
MANIFOLD, (See SERVICE AND BRAKE for Breakdown)
