SECTION 2 - BOOM
56 644E-42,944E-42 8990462
ITEM PART NUMBER QTY DESCRIPTION REV
403 7300034 1 WEAR PAD
404 8303778 2 HEX HD CAPSCREW, M10X40, GR8.8, (torque to 34-61 Nm)
501 Ref TILT COMPENSATION CYLINDER, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
502 7137142 2 PIN
503 8305654 2 HEX LOCKNUT, M8X90, (torque to 17-31 Nm/13-23 lb-ft)
504 8310424 2 HEX HD CAPSCREW, M8X90, GR 8.8
505 8520001 2 GREASE FITTING
506 91143220 7 in TRIM LOCK
601 Ref LIFT CYLINDER, (See HYDRAULIC COMPONENTS SECTION
for Breakdown)
602 7139886 1 SPACER
603 7300580 1 PIN
604 8310218 1 HEX HD CAPSCREW, M12X55, GR8.8
605 8310625 1 HEX NUT, M12X1.75, (torque to 59-106 Nm/43-106 lb-ft)
606 8310657 1 WASHER, 12mm
607 8310691 2 SELF-LUBE SHIM
701 7301309 2 SCRAPER PLATE
702 8303798 4 HEX HD CAPSCREW, M10X25, GR8.8
703 8307221 4 WASHER, 10mm
801 7300716 2 BUSHING
802 805001 3 BEARING
803 8050085 2 BEARING
804 1001125711 1 TRANSFER CARRIAGE WELDMENT
804 7301102 1 TRANSFER CARRIAGE WELDMENT
853 7300572 2 BOOM PIVOT PIN
856 8302446 2 COTTER PIN
861 8310662 2 CLEVIS PIN
862 8310689 2 SELF-LUBE SHIM
863 8307912 2 SHIM
864 8307913 4 SHIM
901 Ref PIN, (See FRAME AND ATTACHING PARTS SECTION for
Breakdown)
902 Ref RETAINING RING, (See FRAME AND ATTACHING PARTS
SECTION for Breakdown)
903 Ref TRANSFER CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
