SECTION 1 - FRAME AND ATTACHING PARTS
8990462
644E-42,944E-42
25
FIGURE 1-5. ENGINE POD INSTALLATION (644E SN 1600408717 to Present, Including 0160045421;
944E SN 160041827 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001112264
Ref
ENGINE POD INSTALLATION, (not available to order, see items 1
thru 11 for service)
C
1
0683020
4
HEX HD CAPSCREW, 1-1/4X2-1/2, GR8, (torque to 1213 to 2183
lb-ft/1645-2960 Nm)
2
8310539
4
WASHER, 1-1/4
3
1001112271
1
WELDMENT
4
0761010
15
HEX HD CAPSCREW, M10X20, GR8.8, (torque to 50 Nm/37 lb-ft)
5
4832000
15
LOCKWASHER, 10mm
6
90206196
7.5 in
TRIM
7
1001125456
1
COOLER COVER PLATE
8
1001125457
1
ENGINE COVER PLATE
9
1001125458
1
ENGINE POD COVER PLATE
10
1001125459
1
ENGINE POD COVER PLATE
11
1001125720
1
ENGINE POD COVER PLATE, (includes item 51)
B
51
1001125721
1
FOAM SEAL
1001125402
Ref
ENGINE POD COVER INSTALLATION, (not available to order, see
items 101 thru 104 for service)
A
101
8305654
2
HEX NUT, M8X1.25
102
8307203
12
WASHER, 5/16
103
8310693
10
HEX FLANGE SCREW, M8X25, GR8.8, (torque to 13-23 lb-ft/18-
31 Nm)
104
1001125401
1
ENGINE POD COVER ASSEMBLY
1001112381
Ref
HOOD INSTALLATION, (not available to order, see items 201 thru
213 for service)
C
201
7300687
1
GAS STRUT BRACKET
202
7301370
1
LATCH ASSEMBLY, (includes items 301 thru 307)
AB
203
7301526
AR
10 GAUGE SHIM
204
7301527
AR
16 GAUGE SHIM
205
8303784
8
HEX HD CAPSCREW, M10X20, GR8.8, (torque to 25-44 lb-ft/34-
60 Nm)
206
8310621
8
WASHER, 10mm
207
8340038
2
BALL STUD, 10mm, (torque to 12-21 lb-ft)
208
8702164
4
SPRING RETAINER CLIP
209
1001112382
1
HOOD ASSEMBLY, (includes items 401 thru 414)
D
210
8702162
2
GAS SPRING
213
1001125463
1
FOAM SEAL
301
7301312
1
HOOD LATCH PLATE
302
7301371
1
LATCH CATCH PLATE
303
7301372
AR
HOOD LATCH PLATE
304
7301373
AR
LATCH CATCH PLATE, 7 GA SPACER
305
7301526
AR
20 GAUGE SHIM
306
7301527
AR
16 GAUGE SHIM
307
8303777
2
HEX HD CAPSCREW, M10X35, GR8.8, (torque to 34-61 Nm/25-45
Nm)
401
3290405
4
HEX LOCKNUT, M4X0.7
402
7300364
1
HOOD LATCH ASSEMBLY
402
8342813
1
HOOD LATCH KEY
403
7300634
1
REAR HINGE BRACKET
404
7300645
1
GAS SPRING BRACKET
405
7300943
1
FRONT HINGE BRACKET
