SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
267
FIGURE 5-42. ZF TRANSMISSION - COUPLING GROUP 2 944E
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
7026761
2
PISTON RING
2
1319615
1
ROLLER BEARING
3
7026763
1
COUPLING
4
8036575
1
PISTON
5
1319595
5
CUP SPRING
6
1319596
1
SHIM
7
10731845
2
RETAINING RING
8
7026759
8
O. CLUTCH DISC
9
7026758
8
LIN. CLUTCH DISC
10
7026760
1
END SHIM
11
1319600
1
SNAP RING, 3.5mm
11
1319601
1
SNAP RING, 3.5mm
11
1319602
1
SNAP RING, 3.0mm
11
1319603
1
SNAP RING, 2.5mm
11
1319604
1
SNAP RING, 2.0mm
11
7029849
1
SNAP RING, 3.25mm
11
7029850
1
SNAP RING, 3.75mm
11
7029851
1
SNAP RING, 2.25mm
11
7029852
1
SNAP RING, 2.75mm
12
1319606
2
ROLLER CAGE
13
1319614
1
DISC CARRIER
14
7029532
1
OUTER RING
14
7029533
1
INNER RING
