SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
159
FIGURE 5-1. DRIVE TRAIN COMPONENTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
8310671
8
HEX HD CAPSCREW, M24X340, GR10.9, (torque to 500-575 lb-
ft/677-780 Nm)
2
8310061
16
WASHER, 1
3
8310672
8
HEX LOCKNUT, M24X3
4
8303790
4
HEX HD CAPSCREW, M12x30, GR8.8, (torque to 69-78 lb-ft/94-
105 Nm)
5
8307220
4
WASHER, 12mm
6
Ref
GEAR PUMP, (See HYDRAULIC COMPONENTS SECTION for
Breakdown)
7
8630019
1
O-RING
8
Ref
DRIVESHAFTS, (See DRIVE SHAFTS for Breakdown )
9
Ref
FRONT AXLE, (See FRONT AXLE for Breakdown)
10
Ref
REAR AXLE, (See REAR AXLE for Breakdown)
11
Ref
ZF TRANSMISSION, (See ZF TRANSMISSION for Breakdown)
12
8303769
12
HEX HD CAPSCREW, M10X45mm, GR8.8
13
8303798
4
HEX HD CAPSCREW, M10X25mm, GR8.8
14
8786572
32
WHEEL NUT, (torque to 425-450 lb-ft/576-610 Nm) (644E Prior to
SN 0160039830, Excluding 0160036724, 0160036811,
0160036907 and 0160037012; 944E Prior to SN 0160040124,
Excluding 0160034634, 0160036710, 0160036722, 0160036735
and 0160036738)
14
8786572
40
WHEEL NUT, (torque to 425-450 lb-ft/576-610 Nm) (644E SN
0160039830 to Present, Including 0160036724, 0160036811,
0160036907 and 0160037012; 944E SN 0160040124 to Present,
Including 0160034634, 0160036710, 0160036722, 0160036735
and 0160036738)
14
91403193
40
WHEEL NUT, (if equipped with Firestone 370/75-28), (torque to
430-470 lb-ft/583-637 Nm) (644E SN 0160039830 to Present,
Including 0160036724, 0160036811, 0160036907 and
0160037012; 944E SN 0160040124 to Present, Including
0160034634, 0160036710, 0160036722, 0160036735 and
0160036738)
15
8786573
32
SPRING WASHER (644E Prior to SN 0160039830, Excluding
0160036724, 0160036811, 0160036907 and 0160037012; 944E
Prior to SN 0160040124, Excluding 0160034634, 0160036710,
0160036722, 0160036735 and 0160036738)
15
8786573
40
SPRING WASHER, (not required with Firestone 370/75-28) (644E
SN 0160039830 to Present, Including 0160036724, 0160036811,
0160036907 and 0160037012; 944E SN 0160040124 to Present,
Including 0160034634, 0160036710, 0160036722, 0160036735
and 0160036738)
16
Ref
TIRE AND RIM ASSY, (See TIRE AND RIMS for Breakdown)
17
7300445
1
TRANSMISSION MOUNTING PLATE
18
8310288
2
HEX HD CAPSCREW, 5/8-11X3-3/4, GR8
19
8278040
2
ENGINE ISOLATOR
20
7300435
2
REBOUND WASHER
21
8305643
2
HEX LOCKNUT, 3/4-11
22
8310379
6
HEX HD CAPSCREW, M16X45, GR10.9
23
3576011
1
MOUNTING PLATE (644E SN 0160012410 to Present; 944E SN
0160012745 to Present)
