SECTION 3 - ATTACHMENTS
8990462 644E-42,944E-42 75
FIGURE 3-9. SHEET MATERIAL HANDLER (Prior to SN 0160037794)
ITEM PART NUMBER QTY DESCRIPTION REV
7129300 1 SHEET MATERIAL HANDLER WITH 72 IN SWING CARRIAGE
ASSY, (includes items 1 thru 13)
7112704 1 SHEET MATERIAL HANDLER WITH 72 IN SWING CARRIAGE
ASSY, (includes items 1 thru 13) E
1 7112533 1 RIGHT SIDE FORK SUPPORT
2 7112523 1 LEFT SIDE FORK SUPPORT
3 7112642 2 BACKREST EXTENSION
4 8303626 6 HEX HD CAPSCREW, 1/2-13X1-1/2
5 8307007 6 LOCKWASHER, 1/2
6 8305012 4 HEX NUT, 1/2-13
7 8301456 2 HITCH PIN
9 N.S.S. 2 SN PLATE
11 7114941 2 Lock Bar
12 8305644 2 HEX LOCKNUT, 1/2-13
13 8307112 2 FLAT WASHER, 1/2
15 Ref 72 IN SWING CARRIAGE, (See SWING CARRIAGE for
Breakdown)
