SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
257
FIGURE 5-37. ZF TRANSMISSION - ENGINE CONNECTION AND INPUT SHAFTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
7026744
4
HEX HD CAPSCREW, M10X16
2
7026745
8
THRUST WASHER, 1
3
1319229
2
DIAPHRAGM
4
7027256
1
CONVERTER
5
1319576
1
SHAFT SEAL
6
70021526
1
CONVERTER BELL
7
1319571
2
CYLINDRICAL PIN
8
7026775
15
HEX HD CAPSCREW, M10X80
9
80304394
21
HEX HD CAPSCREW, M10X30
10
7026774
1
GASKET
11
7026769
2
ROLLER BEARING
12
7026771
1
SHAFT
13
7026772
1
PISTON RING, 67X3.00
14
7026748
1
STATOR SHAFT
15
1319558
1
BEARING BUSHING
16
7026747
1
TURBINE SHAFT
17
1319585
2
CAPSCREW, M8X16
18
N.S.S.
2
SHACKLE
19
80304405
1
RETAINING RING, 55X2.00
20
7026749
1
PISTON RING
21
1319563
1
BEARING BUSHING
22
1319641
1
SHAFT SEAL
23
Ref
GEARBOX HOUSING, (See ZF TRANSMISSION - GEARBOX
HOUSING AND COUPLING LOCATION for Breakdown)
24
Ref
OIL PUMP, (See ZF TRANSMISSION - OIL PUMP for Breakdown)
