SECTION 8 - HYDRAULIC CIRCUITS
8990462
644E-42,944E-42
373
FIGURE 8-3. PUMP, SUCTION AND RETURN (644E SN 0160048717 to Present, Including 0160045421;
944E SN 0160041827 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001112352
Ref
HYDRAULIC COMPONENT INSTALLATION, (not available to
order, see items 1 thru 46 for service) (944E SN 0160041827
through 0160045848)
D
1001138002
Ref
HYDRAULIC COMPONENT INSTALLATION, (not available to
order, see items 1 thru 46 for service) (644E SN 0160048717 to
Present, Including 0160045421; 944E SN 0160045879 to
Present)
A
1
2716911
1
HOSE
2
8303790
2
HEX HD CAPSCREW, M12X30, GR8.8, (torque to 33-66 lb-ft/44-
90 Nm)
4
8307220
6
WASHER, 12mm
5
8310164
4
HEX HD CAPSCREW, M12X40, GR8.8, (torque to 33-66 lb-ft/44-
90 Nm)
6
8405209
2
T-BOLT CLAMP
8
1001112354
1
HYDRAULIC TANK RETAINER ASSEMBLY, (includes items 708
& 709)
B
11
Ref
HYDRAULIC TANK, (See HYDRAULIC COMPONENTS SECTION
for Breakdown)
12
1001112368
1
HYDRAULIC TANK SUPPORT BRACKET
12
1001112370
1
FOAM SEAL
14
0681812
4
HEX HD CAPSCREW, 1/2-13X1-1/2, GR8
15
0761210
2
HEX HD CAPSCREW, M12X20, GR8.8
16
4761800
4
LOCKWASHER, 1/2
17
7130131
2
SPACER
18
7139980
1
BREATHER ASSEMBLY
19
8275212
1
MUFFLER CLAMP, 2-1/2 IN, U TYPE, (torque to 25-30 lb-ft/34-41
Nm)
20
8303550
2
HEX HD CAPSCREW, M8X60, GR8.8
21
8303703
2
HEX HD CAPSCREW, 1/4-20X2-1/2, GR5
22
8305654
1
HEX NUT, M8X1.25
23
8310623
1
CARRIAGE BOLT, M8X25, GR8.8
24
8410001
1
HOSE CLAMP
25
8410009
5
GEAR CLAMP, (torque to 0.33 lb-ft/.44 Nm)
26
8430099
1
BARBED HOSE TEE, FOR 1/2 ID HOSE
27
8530036
2
FLANGE HALF
28
8630009
1
O-RING
29
8750001
1
SINGLE COVER PLATE
30
8750005
1
SINGLE CLAMP SET
31
8750022
2
TWIN CLAMP SET
32
8750025
2
TWIN COVER PLATE
33
8902856
1
CHECK VALVE
34
1001121963
1
RETURN TUBE
35
1001112377
1
SUPPLY TUBE (944E SN 0160041827 through 0160045848)
35
1001137961
1
SUPPLY TUBE (644E SN 0160048717 to Present, Including
0160045421; 944E SN 0160045879 to Present)
36
1001112379
1
TUBE MOUNT BRACKET
37
1001112601
1
HOSE
38
1001112602
1
HOSE
39
1001112603
1
HOSE
40
1001116181
1
RETURN TUBE
41
2717029
1
HOSE
