SECTION 4 - ENGINE AND ATTACHING PARTS
8990462
644E-42,944E-42
155
FIGURE 4-16. EXHAUST INSTALLATION (644E SN 0160048717 to Present, Including 01600405421;
944E SN 0160041827 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001112327
Ref
EXHAUST INSTALLATION, (not available to order, see items 1 thru
21 for service)
C
1
5201012
2
RIPP BOLT, M10X25, (torque to 45-60 lb-ft/61-81 lb-ft)
2
5221000
2
RIPP NUT, 10mm
3
7301165
1
MUFFLER BRACKET
4
8275247
3
3IN HEAVY DUTY CLAMP
5
8303551
2
HEX HD CAPSCREW, M10X16, GR8.8, (torque to 45-60 lb-ft/61-
81 lb-ft)
6
8303798
4
HEX HD CAPSCREW, M10X25, GR8.8, (torque to 45-60 lb-ft/61-
81 lb-ft)
7
8305038
2
HEX NUT, M10X1.5
8
8310621
6
WASHER, 10mm
9
8526007
AR
LOCTITE 242
10
91403601
2
PIPE CLAMP
11
1001100044
1
EXHAUST TAILPIPE
12
1001100849
1
ROUND MUFFLER
13
1001107559
2
MUFFLER CLAMP
14
1001112328
1
EXHAUST SUPPORT
15
1001112329
1
EXHAUST PIPE
16
1001112330
1
EXHAUST PIPE
17
1001114940
1
EXHAUST TUBE
18
8410011
4
GEAR CLAMP, 3.25IN
19
1001120988
1
EXHAUST COVER
20
1001132367
1
THERMAL INSULATION
21
1001132368
1
THERMAL INSULATION
