SECTION 7 - CONTROLS
8990462 644E-42,944E-42 343
FIGURE 7-1. SERVICE BRAKE AND PEDAL ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
1 8902316 1 BRAKE VALVE (644E Prior to SN 0160039830, Excluding
0160036724, 0160036811, 0160036907 and 0160037012; 944E
Prior to SN 0160040124, Excluding 0160034634, 40160036710,
0160036722, 0160036735 and 0160036738)
1 1001103493 1 BRAKE VALVE (644E SN 0160039830 to Present, Excluding
0160036724, 0160036811, 40160036907 and 0160037012; 944E
SN 0160040124 to Present, Excluding 0160034634, 0160036710,
0160036722, 0160036735 and 0160036738)
2 8310476 2 HEX HD CAPSCREW, M8X35, GR 8.8
3 8307222 2 PLAIN WASHER, M8
4 8305638 2 HEX LOCKNUT, M8X1.25
5 8630020 2 SNAP RING, .75 INTERNAL HEAVY DUTY
6 8310508 3 SHIM WASHER, .755X.075X1.25
7 8310507 1 SHIM WASHER, .755X.048X1.25
8 7139108 1 BRAKE PEDAL SHAFT
9 7301066 1 BRAKE PEDAL ASSY, (includes items 10 thru 15) AA
10 7300143 2 OILITE FLANGE BUSHING
11 8303739 1 HEX HD CAPSCREW, 5/16-18X1-1/4, GR 5
12 8310453 1 HEX NUT, 5/16-18, GR 5
13 7300135 2 PIN CLIP
14 7300136 1 SHAFT PIN
15 7300137 1 ROLLER, 1 DIA
16 8700125 1 EXTENSION SPRING, 1.00ODX7.12 LG
17 8303261 1 HEX HD CAPSCREW, M12X100, GR 8.8
18 8305044 1 HEX NUT, M12
19 8307220 2 PLAIN WASHER, M12-1.75
20 8310625 1 HEX LOCKNUT, M12-1.75
21 8223238 1 STABIL-TRAK SWITCH
