SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
255
FIGURE 5-36. ZF TRANSMISSION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001095739
1
TRANSMISSION KIT, (644E - p/n 8841046 & 944E - p/n 8841047
no longer available, order 1001095739 for replacement), (includes
item 1 and items 17 & 22 on DRIVE TRAIN COMPONENTS
C
1
1001095741
NLA
TRANSMISSION ASSY - 4 SPEED, (no longer available, use
1001125968 for replacement or the following items for service)
(644E Prior to SN 0160048717; 944E Prior to SN 0160041827)
C
1
1001125968
1
TRANSMISSION ASSY - 4 SPEED, (includes the following items)
(644E SN 0160048717 to Present, Including 0160045421; 944E
SN 0160041827 to Present)
A
1
Ref
ENGINE CONNECTION AND INPUT SHAFTS, (See ZF
TRANSMISSION - ENGINE CONNECTION AND INPUT
SHAFTS for Breakdown)
1
Ref
GEARBOX HOUSING AND COUPLING LOCATION, (See ZF
TRANSMISSION - GEARBOX HOUSING AND COUPLING
LOCATION for Breakdown)
1
Ref
COUPLING GROUP 1, (See ZF TRANSMISSION - COUPLING
GROUP 1 for Breakdown)
1
Ref
COUPLING GROUP 2, (See ZF TRANSMISSION - COUPLING
GROUP 2 for Breakdown)
1
Ref
COUPLING GROUP 3, (See ZF TRANSMISSION - COUPLING
GROUP 3 for Breakdown)
1
Ref
COUPLING GROUP 4, (See ZF TRANSMISSION - COUPLING
GROUP 4 for Breakdown)
1
Ref
REVERSING GEAR GROUP CV, (See ZF TRANSMISSION -
REVERSING GEAR GROUP CV for Breakdown)
1
Ref
REVERSING GEAR GROUP CR, (See ZF TRANSMISSION -
REVERSING GEAR GROUP CR for Breakdown)
1
Ref
OIL PUMP, (See ZF TRANSMISSION - OIL PUMP for
Breakdown)
1
Ref
CONTROL UNIT, (See ZF TRANSMISSION - CONTROL UNIT
for Breakdown)
1
Ref
GEARSHIFT SYSTEM, (See ZF TRANSMISSION - GEARSHIFT
SYSTEM for Breakdown)
1
Ref
TRANSFER BOX, (See ZF TRANSMISSION - TRANSFER BOX
for Breakdown)
