SECTION 12 - OPTIONS
8990462
644E-42,944E-42
609
FIGURE 12-7. COLD START OPTION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
8225122
2
4 POST RELAY, (includes items 2 thru 5)
2
8307003
2
LOCKWASHER, #10
3
8305003
2
HEX NUT, #10-32
4
N.S.S.
2
LOCKWASHER, 5/16
5
N.S.S.
2
HEX NUT, 5/16-24
6
8270423
1
INTAKE AIR HEATER, 12 VDC, 195 AMP
7
8270424
2
GRID HEATER GASKET
8
8270425
1
HEATER CONTROL MODULE
9
8270426
1
GRID HEATER CONTROL TEMPERATURE SENSOR
10
8270427
2
GRID HEATER DECAL
11
7300535
1
UPPER BATTERY SUPPORT
12
8307221
1
FLAT WASHER, M10
13
8310070
1
PUSHNUT, 3/8X13/16O.D.
14
8310709
1
CLAMP KNOB STUD, M10-1.5X40mm
15
7300346
1
COLD START HARNESS, (includes items 16 thru 18)
16
8220357
2
CLEAR VES-PAC COVER
17
8220364
1
2 DIODE CIRCUIT BOARD
18
8220366
1
3 DIODE CIRCUIT BOARD
19
4923215
1
NEGATIVE BATTERY CABLE
20
4923214
1
POSITIVE BATTERY CABLE
21
7301448
2
GRID HEATER CABLE, FUSE TO RELAY
22
7301449
2
GRID HEATER CABLE, BATTERY TO FUSE (Prior to SN
0160010079, Excluding 0160009717)
22
4923225
2
GRID HEATER CABLE, BATTERY TO FUSE (SN 0160010079 to
Present, Including 0160009717)
23
7301450
2
GRID HEATER CABLE, RELAY TO GRID HEATER
24
8229259
2
MEGA BOLT FUSE, 125 AMP
25
8229260
2
FUSE HOLDER, (includes items 26 & 27)
26
N.S.S.
2
LOCKWASHER, M8
27
N.S.S.
2
HEX NUT, M8
28
8270144
1
12 VOLT BATTERY, GROUP 27, 850 CCA
29
8270145
1
BATTERY HOLD DOWN BRACKET ASSY
30
8270146
2
BATTERY HOLD DOWN BOLT ASSY
31
8270147
1
NEGATIVE BATTERY CLAMP
32
8270148
1
POSITIVE BATTERY CLAMP
33
8303544
6
HEX HD CAPSCREW, M6-1.0X20mm, PC8.8, (torque to 7-12.5
Nm)
34
8303545
4
HEX HD CAPSCREW, M6-1.0X14mm, PC8.8
35
8305652
2
LOCK HEX NUT, M6-1.0
36
8307219
10
FLAT WASHER, M6
37
8584001
12
TIE WRAP
38
7125861
1
CONDUIT, 75IDX60 LG, (cut to fit)
39
7301893
1
BATTERY TERMINAL INSULATOR
40
8305047
2
HEX LOCKNUT, M6-1.0
41
8310687
2
LOCKWASHER, M6, (external tooth)
K1
8270422
1
GRID HEATER KIT, (includes items 1 thru 10)
