SECTION 8 - HYDRAULIC CIRCUITS
394
644E-42,944E-42
8990462
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
49
2717065
1
HOSE ASSEMBLY
50
2717066
1
HOSE ASSEMBLY
51
2717132
1
HOSE ASSEMBLY (SN 19386 through 19605)
52
2717131
1
HOSE ASSEMBLY (SN 19386 through 19605)
53
2110808
3
CONNECTOR
54
8770127
2
ELBOW, 45
55
2110606
1
ADAPTER
56
2717133
1
HOSE ASSEMBLY
57
2170306
1
RUN TEE
58
8770117
2
CONNECTOR
59
8770115
2
ELBOW, 90, (swivel nut)
60
2717253
1
HOSE ASSEMBLY
61
2717252
1
HOSE ASSEMBLY
62
7301438
2
STC HOSES SERVICE TOOL, 8-12
63
7301666
2
12 STC MALE PLUG
64
7301667
2
12 STC FEMALE CAP
65
7301663
6
8 STC FEMALE CAP
66
7301662
6
STC MALE PLUG
67
7020368
16
STC PORT REPAIR SERVICE KIT, (port size - 08), (includes
retaining ring, back-up ring and o-ring)
68
7020369
4
STC PORT REPAIR SERVICE KIT, (port size -12), (includes
retaining ring, back-up ring and o-ring)
69
Ref
AUX PRESS DUMP VALVE SOLENOID, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
70
Ref
MANIFOLD, (See SERVICE AND PARKING BRAKE for
Breakdown)
71
Ref
ATTACHMENT TILT CYLINDER, (See HYDRAULIC
COMPONENTS SECTION for Breakdown)
72
Ref
MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
K1
8024045
1
STC HOSE CONNECTIONS SERVICE KIT, (includes items 62 thru
66)
