SECTION 10 - ELECTRICAL
8990462
644E-42,944E-42
527
FIGURE 10-2. BATTERY AND VEHICLE GROUND CABLES (Prior to SN 0160041827)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
8270144
2
12V BATTERY
2
8270146
4
BATTERY HOLD DOWN BOLT ASSEMBLY
3
8270145
2
BATTERY HOLD DOWN BRACKET ASSEMBLY
4
8270148
2
POSITIVE POLARITY BATTERY CLAMP
5
7301893
2
BATTERY TERMINAL INSULATOR
6
4923214
1
POSITIVE BATTERY CABLE, (dual)
7
7300341
1
POSITIVE BATTERY CABLE
8
8270147
2
NEGATIVE POLARITY BATTERY CLAMP
9
4923215
1
NEGATIVE BATTERY CABLE, (dual)
10
7300342
1
NEGATIVE BATTERY CABLE
11
8406201
1
TUBE CLIP, 1-1/2
12
8310647
4
LOCKWASHER, 8mm, (external tooth)
13
6611172
2
GROUND STRAP
14
8307222
2
WASHER, 8mm
15
8305654
2
HEX LOCKNUT, M8X1.25
16
7300343
1
FRAME GROUNDING CABLE
17
8305038
1
HEX LOCKNUT, M10X1.5
18
8310046
2
LOCKWASHER, 10mm, (external tooth)
19
8307221
1
WASHER, 10mm
20
Ref
STARTER, (See ENGINE AND ATTACHING PARTS SECTION for
Breakdown)
21
Ref
LOWER BATTERY SUPPORT, (See FRAME AND ATTACHING
PARTS SECTION for Breakdown)
22
Ref
GROUNDING HARDWARE, (See POWER COMPONENTS for
Breakdown)
23
Ref
GROUND CABLE, (See OPEN CAB ELECTRICAL COMPONENTS
for Breakdown)
24
1560020
2
SPLIT CORRUGATED CONDUIT
