Page 13
SECTION 1 - FRAME AND ATTACHING PARTS
8990462
644E-42,944E-42
13
FIGURE 1-1. MAIN FRAME COMPONENTS 644E (Prior to SN 0160048717, Excluding 0160045421)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
N.S.S.
1
MAIN FRAME
2
8307221
3
PLAIN WASHER, 10mm
3
8303755
3
HEX HD CAPSCREW, 10X1.5X30mm, GR8.8
4
7300534
1
LOWER BATTERY SUPPORT
5
7300260
1
ENGINE MOUNT FRAME
6
8310625
2
HEX LOCKNUT, 12-1.75mm
7
7301149
2
CYLINDER MOUNTING PIN
8
7139886
2
PIN RETAINER SPACER
9
8310657
2
PLAIN WASHER,12 mm
10
8310656
2
HEX HD CAPSCREW, 12-1.75X60mm, GR8.8
11
7301096
NLA
LULL LOGO PLATE, (no longer available, use items 33 & 34 for
replacement)
12
7301098
NLA
LOGO BACKUP PLATE, (no longer available, use items 33 & 34 for
replacement)
13
8307220
4
FLAT WASHER, 12mm
14
8310625
4
HEX LOCKNUT, 12-1.75mm
15
8310424
2
HEX HD CAPSCREW, 8-1.25X90mm, GR8.8
16
7137142
2
CYLINDER PIN
17
8520001
2
LUBE FITTING, 1/8
18
8305654
2
HEX LOCKNUT, M8-1.25
19
8050001
2
SELF ALIGN BEARING, 1.4995X1.307
20
8310539
4
PLAIN WASHER, 1.25-1.375-2.5
21
0683020
4
HEX HD CAPSCREW, 1.25-7-2.5, GR8
22
Ref
HEX HD CAPSCREW, 1.25-7-4, GR8, (See CAB SECTION for
Breakdown)
23
Ref
CAB SUPPORT WASHER, (See CAB SECTION for Breakdown)
24
Ref
CAB MOUNT SHEER PIN, (See CAB SECTION for Breakdown)
25
Ref
CAB REAR SUPPORT, (See CAB SECTION for Breakdown)
26
Ref
HEX HD CAPSCREW, 12-1.75X40mm, GR8.8, (See CAB
SECTION for Breakdown)
27
Ref
PLAIN WASHER, 0.5, (See CAB SECTION for Breakdown)
28
Ref
HEX HD CAPSCREW, 12-1.75X40mm, GR8.8, (See CAB
SECTION for Breakdown)
29
Ref
CAB MOUNT STEP, (See CAB SECTION for Breakdown)
30
Ref
CAB FRONT SUPPORT, (See CAB SECTION for Breakdown)
31
8321701
4
HEX HD CAPSCREW, 20-2.5X150mm, GR8.8
32
7300754
2
TC STOP BLOCK
33
3575924
1
FRAME COVER PLATE
34
10704216
4
HEX HD CAPSCREW, 12-1.75X110mm, GR8.8
35
Ref
FRONT AXLE, (See DRIVE TRAIN SECTION for Breakdown)
36
Ref
REAR AXLE, (See DRIVE TRAIN SECTION for Breakdown)
37
Ref
FRAME SWAY CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
38
Ref
STABIL-TRAK CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
