Page 211
SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
211
FIGURE 5-19. FRONT AXLE - PLANETARY DRIVE (Prior to SN 0160040124, Excluding 0160034634,
0160036710, 0160036722, 0160036735 and 0160036738)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
80304227
3
RETAINING RING
2
1321205
6
SNAP RING
3
1321191
6
WASHER
4
1321214
3
ROLLER BEARING
5
1321233
3
PLANET GEAR
6
8035977
2
CAP SCREW
7
1319506
1
SCREW PLUG
8
8036331
1
O-RING
9
1321232
1
PLANET CARRIER
10
1321255
1
SUN GEAR SHAFT
11
1321258
1
RING GEAR
