Lull 944E-42 Parts Manual User Manual
Page 238
SECTION 5 - DRIVE TRAIN
238
644E-42,944E-42
8990462
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
9
1319506
2
SCREW PLUG
10
1319505
2
BREATHER
11
1319666
2
SCREW PLUG
12
7027217
2
O-RING
13
8035936
Ref
BRAKE HOUSING, (left side), (see note), (Axle) (Prior to SN
679469)
13
70020483
1
BRAKE HOUSING, (left side), (Axle) (SN 679469 to Present)
13
8035939
Ref
BRAKE HOUSING, (right side), (see note), (Axle) (Prior to SN
679469)
13
70020484
1
BRAKE HOUSING, (right side), (Axle) (SN 679469 to Present)
14
1321151
2
SUPPORT RING
15
1321162
2
U-RING
16
1321163
2
U-RING
17
1321152
2
SUPPORT RING
18
1319496
16
PIN
19
1319497
16
COMPRESSION SPRING
20
8036305
2
WASHER
21
8036304
2
PISTON
22
1319499
16
CRESCENT RING
23
1319504
4
SNAP RING
24
10731949
2
RETAINING RING
25
1321174
2
DISC CARRIER, (Axle) (Prior to SN 824742)
25
70020409
1
DISC CARRIER, (Axle) (SN 824742 to Present)
26
1319502
16
O. CLUTCH DISC, 3.0mm, (Axle) (Prior to SN 679469)
26
70020486
8
O. CLUTCH DISC, 2.5mm, (Axle) (SN 679469 to Present)
26
70020487
8
O. CLUTCH DISC, 3.0mm, (Axle) (SN 679469 to Present)
27
1319500
4
O. CLUTCH DISC, 2.0mm, (Axle) (Prior to SN 679469)
27
70020485
4
O. CLUTCH DISC, 2.0mm, (Axle) (SN 679469 to Present)
27
1319501
4
O. CLUTCH DISC, 2.5mm, (Axle) (Prior to SN 679469)
27
70020486
4
O. CLUTCH DISC, 2.5mm, (Axle) (SN 679469 to Present)
27
1319502
4
O. CLUTCH DISC, 3.0mm, (Axle) (Prior to SN 679469)
27
70020487
4
O. CLUTCH DISC, 3.0mm, (Axle) (SN 679469 to Present)
28
1321150
6
I. CLUTCH DISC, (Axle) (Prior to SN 824742)
28
70020408
3
I. CLUTCH DISC, (Axle) (SN 824742 to Present)
29
Ref
BEVEL GEAR SET, (See REAR AXLE
– INPUT for Breakdown)
30
Ref
DIFFERENTIAL ASSY, (See REAR AXLE
– DIFFERENTIAL for
Breakdown)
N1
Note
Ref
PARTS ARE NO LONGER AVAILABLE; ORDER BRAKE
HOUSINGS 70020483 & 70020484, QUANTITY REQUIRED OF
OUTER DISCS 70020485, 70020486 & 70020487, QUANTITY 2
OF 70020413 END PLATES.
