SECTION 5 - DRIVE TRAIN
8990462
644E-42,944E-42
275
FIGURE 5-46. ZF TRANSMISSION - COUPLING GROUP 4 944E
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
7026761
2
PISTON RING
2
1319615
1
ROLLER BEARING
3
7026770
1
COUPLING
4
8036575
1
PISTON
5
1319595
5
CUP SPRING
6
1319596
1
SHIM, 2.0mm
7
10731845
2
RETAINING RING
8
7026759
8
O. CLUTCH DISC
9
7026758
8
LIN. CLUTCH DISC
10
7026760
1
END SHIM
11
1319600
1
SNAP RING, 3.5mm
11
1319601
1
SNAP RING, 3.5mm
11
1319602
1
SNAP RING, 3.0mm
11
1319603
1
SNAP RING, 2.5mm
11
1319604
1
SNAP RING, 2.0mm
12
1319635
1
DISC CARRIER
13
1319606
2
ROLLER CAGE
14
1319636
1
ROLLER BEARING
