SECTION 2 - BOOM
8990462 644E-42,944E-42 49
FIGURE 2-8. BOOM EXTEND CHAIN
ITEM PART NUMBER QTY DESCRIPTION REV
7300076 Ref EXTEND CHAIN ASSY, (includes all items) D
1 7300911 1 EXTEND CHAIN AND CLEVIS ASSY
2 8310651 1 HEX HD CAPSCREW, 16-2.0X100mm, PC8.8
3 8310217 1 HEX LOCKNUT, 16-2.0mm
4 7117582 1 EXTEND CHAIN SHEAVE PIN
5 1001101867 1 BUSHING SHEAVE ASSY A
5 7117502 2 CHAIN SHEAVE BUSHING
5 7114032 1 EXTEND CHAIN SHEAVE
7 8520001 1 GREASE FITTING, 1/8
8 7300078 1 CLEVIS RETAINER BRACKET
9 8307025 1 LOCKWASHER, 12mm
10 8303790 1 HEX HD CAPSCREW, 12-1.75X30mm, PC8.8
11 8642236 2 RETAINING RING
12 7300613 1 CLEVIS PIN
13 8522012 AR ANTI-SEIZE LUBE, (apply to items 4 & 12)
