SECTION 10 - ELECTRICAL
8990462
644E-42,944E-42
551
FIGURE 10-11. CLOSED CAB ELECTRICAL COMPONENTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
7300411
1
CLOSED CAB HARNESS (644E SN 17569 through 20123, SN
0160002514 through 0160034284; 944E SN 17569 through
20123, SN 0160002514 through 0160034278)
H
1
1001092360
1
CLOSED CAB HARNESS (644E SN 0160034285 to Present; 944E
SN 0160034279 to Present)
A
2
7301260
1
HEATER CONTROL PANEL, (includes items 5, 6 & 8)
3
8310692
4
NYLON PUSH RIVET, 5.1mm DIA, 4.5mm GRIP
5
8036438
2
POSITIONING KNOB
6
8036463
1
BLOWER CONTROL SWITCH
7
7301265
1
AIR CONDITIONING ROCKER SWITCH
8
8036603
1
TEMPERATURE CONTROL SWITCH
9
8223043
1
WINDSHIELD WIPER SWITCH
10
8223044
1
WINDSHIELD WASHER SWITCH
11
8223040
1
ROOF WIPER/WASHER SWITCH
12
7301261
1
ELECTRIC HEAT VALVE
13
Ref
3 POSITION BEZEL SWITCH, (See CAB SECTION for Breakdown)
14
Ref
REAR WINDOW WIPER ASSY, (See CAB SECTION for
Breakdown)
15
Ref
FRONT WINDSHIELD WIPER ASSY, (See CAB SECTION for
Breakdown)
16
Ref
SKYLIGHT WIPER ASSY, (See CAB SECTION for Breakdown)
17
Ref
HEATER SYSTEM, (See CAB SECTION for Breakdown)
18
Ref
AIR CONDITIONING SYSTEM, (See CAB SECTION for
Breakdown)
19
Ref
FUSE/RELAY BOX, (See FUSES, RELAYS AND FLASHER BOX
for Breakdown)
20
Ref
GROUND WIRES, (See OPEN CAB ELECTRICAL COMPONENTS
for Breakdown)
