SECTION 9 - HYDRAULIC COMPONENTS
8990462
644E-42,944E-42
505
FIGURE 9-35. HYDRAULIC TANK ASSEMBLY (644E Prior to SN 0160048717, Excluding 0160045421;
944E SN 0160041827 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
7300226
1
RESERVOIR ASSY, (includes items 1 thru 9, 11 & 12)
H
1
7300229
NLA
HYDRAULIC TANK ASSY, (no longer available, use 1001092281
for replacement) (644E SN 17569 through 20123, SN 0160002514
through 0160029565; 944E SN 17569 through 20123, SN
0160002514 through 0160029564)
1
1001091304
1
HYDRAULIC TANK ASSY (644E SN 0160029567 through
0160043356; 944E SN 0160029566 through 0160041823)
2
7300537
1
RETURN FILTER ASSY, (includes items 101 thru 104)
C
3
7300538
1
FILLER CAP WITH STRAINER ASSY, (includes items 201 thru 205)
B
4
7300539
1
HYDRAULIC RESERVOIR FITTING KIT, (includes items 1 & 301
thru 303)
C
5
7138740
1
SUCTION STRAINER, (torque to 65-85 lb-ft/88-115 Nm)
5
7029716
1
O-RING
6
8223240
1
DUAL TEMPERATURE SWITCH, (torque to 25-40 lb-ft/34-54 Nm)
7
4100181
1
HYDRAULIC OIL FILL DECAL (644E SN 17569 through 20123;
644E SN 0160002514 through 0160025030; 944E SN 17569
through 20123, SN 0160002514 through 0160025029)
7
1707079
1
HYDRAULIC OIL FILL DECAL (644E SN 0160025031 through
0160043356; 944E SN 0160025032 through 0160041823)
8
4108302
1
HYDRAULIC OIL LEVEL DECAL (644E SN 17569 through 20123,
SN 0160002514 through 0160025030; 944E SN 17569 through
20123, SN 0160002514 through 0160025029)
8
1707114
1
HYDRAULIC OIL LEVEL DECAL (644E SN 0160025031 through
0160043356; 944E SN 0160025032 through 0160041823)
9
1707077
1
BATTERY EXPLOSION, WARNING DECAL
10
8320055
1
GASKET
11
0100087
AR
GASKET SEALANT ADHESIVE
12
91563136
1
FLUID LEVEL GAUGE (644E SN 0160015631 through
0160043356; 944E SN 0160015628 through 0160041823)
101
8320053
1
HEAD AND ELEMENT FILTER ASSY
101
8320054
1
HYDRAULIC OIL FILTER, (not shown)
101
7028932
1
SEAL KIT
101
8320055
1
GASKET
102
8223526
1
HYDRAULIC OIL FILTER PRESSURE SWITCH, (torque to 25-40
lb-ft/34-54 Nm)
103
8307221
4
PLAIN WASHER, M10
104
8310668
4
BUTTON HD CAPSCREW, M10X25, GR10.9, (torque to 40-50 lb-
in)
201
7300487
1
FILL NECK ASSY, (includes 202 & 203)
B
202
7300479
1
FILLER CAP, NO BREATHER ASSY
203
0080268
1
FILL NECK ADAPTER
204
7138209
1
HYDRAULIC TANK GASKET
205
8303798
4
HEX HD CAPSCREW, M10x25, GR8.8, (torque to 40-50 lb-in)
301
Ref
CONNECTOR, (See HYDRAULIC CIRCUITS SECTION for
Breakdown)
302
Ref
CONNECTOR, (See HYDRAULIC CIRCUITS SECTION for
Breakdown)
303
8770223
1
SOCKET PLUG, HD #16, (torque to 25-40 lb-ft/34-54 Nm)
401
8430034
2
ELBOW, 90, O-RING BEADED #6-6 (644E SN 17569 through
20123, SN 0160002514 through 0160015606; 944E SN 17569
through 20123, SN 0160002514 through 0160015601)
402
8036627
1
SIGHT GAUGE TUBING (644E SN 17569 through 20123, SN
0160002514 through 0160015606; 944E SN 17569 through
